smartStage 27
Our new power pack. No small stage can take that much load.
Why does a 27 sqm stage need a roof load capacity of 2.5 tons? Because the small band performs in front of a big LED screen that is fixed in the stage roof. Because more load capacity is better than less. Because this stage is able to do it. Furthermore she comes with very attractive optic appearance and proportion and is ready to play within 30 minutes. Even in heavy wind zones.
smartStage 27
Technical data
€5.94 m x 4.56 m
Podium
€5.94 m x 4.56 m
€5.94 m x 5.04 m
Roof
€5.94 m x 5.04 m
€3.53 m
Clearance front
€3.53 m
€0.95 – 1.25 m
Height Podium
€0.95 – 1.25 m
€4.70 m
Height Roof
€4.70 m
€27 qm
Area Podium
€27 qm
€30 qm
AreaDach
€30 qm
€525 kg
/
qm **
Bearing Capacity Podium
€525 kg
/
qm **
€2.520 kg*
Bearing Capacity Roof
€2.520 kg*
€2.450 kg
Tara Weight
€2.450 kg
€150 kg
Pay Load
€150 kg
€7.60 x 2.40 x 3.70 m
Vehicle Dimensions
€7.60 x 2.40 x 3.70 m
* divided load incl. smartWings
** Design load
